Specification Sheet
Part Number:
LTPHC16B-25M
Liquid-Tight Metallic Conduit, Flexible, 0.38" (16mm) Dia, Galvanized Steel w/TPE Cover, Black, 82ft/Reel
Article Number
166-90707
Type
LTPHC16B-25M
Color
Black (BK)
Features & Benefits
• Flexible metallic conduit provides liquid-tight performance to IP66 + IP67 +
IP68 + IP69 when used with LTP or LTPUL fittings. • Helically wound (spiral)
galvanized steel core with an interlocking design delivers high degree of
compression strength and impact resistance. • Smooth thermoplastic TPE-V
rubber protects against corrosion remains flexible at low and high
temperatures. • UV-resistant (black), suitable for outdoor use. • Manufactured
to UL360 requirements. • Halogen free.
Quantity Per
reel
Product Description
A flexible, liquid-tight galvanized steel conduit with a smooth, halogen-free
thermoplastic elastomer coating. LTPHC series is ideal for machinery or
outdoor applications where extreme temperatures exist and liquid-tight
performance is a requirement. Use with HelaGuard LTP or LTPUL Metallic
Fittings for IP66 + IP67 + IP68 + IP69 ratings. May be used in hazardous
locations when accompanied with LTPUL or EXD metallic fittings.
Short Description
Liquid-Tight Metallic Conduit, Flexible, 0.38" (16mm) Dia, Galvanized Steel
w/TPE Cover, Black, 82ft/Reel
Global Part Name
LTPHC16B-25M-GS/TPE-BK
Technical Description
Manufacturer Reference Number: LTPHC16B-25M
Length L (Imperial)
82.0
Length L (Metric)
25.0
Diameter D (imperial)
0.49
Diameter D (metric)
12.6
Outside Diameter OD(Imperial)
0.70
Outside Diameter OD(metric)
17.8
Nominal Diameter (Imperial)
3/8
Nominal Diameter (Metric)
16.0
Material
Thermoplastic Elastomer (TPE) Galvanised Steel (GS)
