Specification Sheet
Part Number:
LTP20-M20-CUL45
Article Number
166-90426
Type
LTS050-45FMC-M20
Color
Metal (ML)
Features & Benefits
• UL Listed to UL514B standards. • Multi-part compression fitting include nylon
seal for ingress protection ratings to IP66 + IP67 + IP68 + IP69. • Durable
Nickel Plated Brass material provides high mechanical strength and resistance
to oil & corrosion. • Suitable for knockouts or Metric threaded entries. •
Interchangeable with all LTP series liquid-tight metallic conduits made to
UL360 sizes. • Suitable for use in hazardous locations as per NEC Article 501
(B)(2): Class I, Division 2; Article 502 (A)(2) & (B)(2) Class II, Division 1 and 2;
and Article 503 (A)(3) & (B)(3) Class III, Divisions 1 and 2.
Quantity Per
pack
Product Description
Multi-part 45 Elbow compresssion fitting with fixed external Metric threads for
liquid-tight performance. Metric threaded fittings supplied with insulated throat
which protects conductors from mechanical damage caused by vibration.
Constructed with Nickel Plated Brass components that resists corrosion,
ensures high mechanical strength and electrical continuity. Metric thread is UL
Listed and suitable for hazardous locations as defined by NEC Article 501.
Fitting comprised of body, nut, grounding ferrule and nylon compression seal.
For use with LTP series liquid tight metallic conduit.
Short Description
HelaGuard Spiral Metallic Fitting, 45-Elbow, Fixed M20 Thread, 0.50" (20mm)
Dia, NPB Metal, 10/pkg
Global Part Name
LTS050-45FMC-M20-NPB/PA6-ML
Technical Description
Manufacturer Reference Number: LTP20-M20-CUL45
Length L (Imperial)
1.95
Length L (Metric)
49.5
Variant
45° Elbow
Height H (Imperial)
1.14
Height H (Metric)
29.0
Nominal Diameter (Imperial)
1/2
Nominal Diameter (Metric)
20.0
Material
Nickel Plated Brass (NPB) Polyamide 6 (PA6)
Material Shortcut
NPB PA6
