Specification Sheet
Part Number:
IMP3.510C2
Identification Marker Plate, 3.5" x .75", Nylon, White, 100/pkg
Article Number
151-42359
Type
IMP3.5
Color
White (WH)
Features & Benefits
•
Identification Marker Plates can be marked with a permanent pen, printed
labels or hot stamped for a wide variety of labeling options. •
Any size bundle
diameter can be marked because it is only dependent upon the length of the
cable tie selected, provided the cable tie width does not exceed .29". •
The
marker plates are stamped from nylon, making them a durable and long term
method of identification. •
The mounting holes are positioned to allow the
marker to be mounted as a flag, tag or wrapped around the cable or bundle for
a wide variety of installed positions.
Quantity Per
bag
Product Description
Identification Marker Plates can be mounted in any direction, either vertically or
horizontally as flags, tags, or wraparound identification plates. They can be hot
stamped or marked with HellermannTyton marking pens (T82-S), thermal
transfer labels, or laser labels. The markers are manufactured from nylon and
are white in color.
Short Description
Identification Marker Plate, 3.5" x .75", Nylon, White, 100/pkg
Global Part Name
IMP3.5-PA66-WH
Length L (Metric)
88.9
Fixation Method
Others
Identification Plate Position
attached to bundle
Variant
Other
Width W (Imperial)
3.5
Width W (Metric)
19.3
Thickness T (Imperial)
0.016
Thickness T (Metric)
0.4
Height H (Imperial)
0.75
Height H (Metric)
19.05
Cable Tie Width Max (Imperial)
0.18
Cable Tie Width Max (Metric)
4.80
Material
Polyamide 6.6 (PA66)
