Specification Sheet
Part Number:
GSTPP-1U24SC
Article Number
853-50048
Type
GSTPP-1U24SC
Color
Black (BK)
Features & Benefits
• Unshielded 24 ports • Flat 1U presentation • Screen printed labelling fields &
port numbers • Accepts HT Connectivity unshielded keystone jacks • Optional
cable management
Quantity Per
box
Product Description
The HellermannTyton range of Modular Keystone panels offer exceptional
flexibility and performance in an angled or flat format in 2U 48 port, 2U 72 port,
1U 48 port and 1U 24 port configurations. The Modular Keystone panels offer
industry standard apertures and are compatible with the HellermannTyton
range of keystone jacks. The use of individual keystone jacks offers a
balanced system performance and also provides simple installation and
maintenance allowing individual jack to be removed if required. Optional rear
cable manager is also available and is sold separately.
Short Description
GST Modular Patch Panel 24 Port, 1U, Steel, Black, 1/box
Global Part Name
GSTPP-1U24SC
Technical Description
The Flat Modular Keystone panel is manufactured from 1.6mm powder coated
mild steel making it rigid and robust. The panel has a matte black powder
coated finish and is screen printed with clear port identification labelling areas
for easy user identification.
Port Count
24
Width W (Imperial)
19.02
Width W (Metric)
483
Height H (Imperial)
1.73
Height H (Metric)
44
Depth D (imperial)
0.43
Depth D (metric)
11
UL Listed (US and Canada)
Yes
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
