Specification Sheet
Part Number:
FU10-25M
HelaGuard Spiral Metallic Conduit, Extra Flexible, 0.25" (10mm) Dia, GS, 82 ft/Reel
Article Number
166-90751
Type
FU10-25M
Color
Metal (ML)
Features & Benefits
•
Inherently low fire hazard material can withstand extreme temperature
conditions. •
Highly durable spiral metallic conduit provides extra flexibility along
with a high degree of compression, tensile and impact strength. •
Provides
ingress protection performance to IP40 when used with FU-M style fittings.
•
Tight bend radius for use in installations requiring constant movement or
vibration.
Quantity Per
reel
Product Description
An extra flexible, galvanized steel conduit used in tight or constrained spaces.
FU-X series is a helically wound, non-UL rated metallic conduit used in
applications that demand higher levels of movement, vibration and bending.
Designed for use where an extra flexible metallic conduit is needed in
machinery for protecting hydraulic or pneumatic hoses or in elevated
temperature conditions. Use with FU-M series metallic fittings for IP40 ratings.
Short Description
HelaGuard Spiral Metallic Conduit, Extra Flexible, 0.25" (10mm) Dia, GS, 82
ft/Reel
Global Part Name
FU10-25M-GS-ML
Technical Description
Manufacturer Reference Number: FU10-25M
Diameter D (imperial)
0.27
Diameter D (metric)
6.8
Outside Diameter OD(Imperial)
0.36
Outside Diameter OD(metric)
9.1
Nominal Diameter (Imperial)
1/4
Nominal Diameter (Metric)
10.0
Material
Galvanised Steel (GS)
Material Shortcut
GS
Flammability
Self-Extinguishing according to EN IEC 61386-1
