Specification Sheet
Part Number:
FSU25-M25-C-S
Metallic Compression Fitting, Straight Swivel, M25 Metric Thread, 3/4" (25mm) Dia, NPB Metal, 10/pkg
Article Number
166-90510
Type
FSU25-M25-C-S
Color
Metal (ML)
Features & Benefits
• Nickel plated brass compression fitting used with FSU, LFHU and FPU
flexible metallic conduit. • Two part swivel fitting comprised of shell, body and
elastomer seal delivers IP65 ingress protection. • External thread swivels about
main body even after tightening.
Quantity Per
pack
Product Description
Two-part nickel plated brass straight fitting with swivel external metric thread.
Fitting comprised of shell and body suitable for knockout or threaded metric
entries. For use with FSU, FPU, and LFHU flexible metal conduit.
Short Description
Metallic Compression Fitting, Straight Swivel, M25 Metric Thread, 3/4" (25mm)
Dia, NPB Metal, 10/pkg
Global Part Name
FSU25-M25-C-S-NPB-ML
Technical Description
Manufacturer Reference Number: FSU25-M25-C-S
Length L (Imperial)
2.00
Length L (Metric)
50.7
Variant
Straight
Height H (Imperial)
1.38
Height H (Metric)
35.0
Nominal Diameter (Imperial)
3/4
Nominal Diameter (Metric)
25.0
Material
Nickel Plated Brass (NPB)
Material Shortcut
NPB
Halogen free
Yes
Operating Temperature (Metric)
-58°F to +275°F (-50°C to +135°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
