Specification Sheet
Part Number:
FSU25-075-C
Metallic Compression Fitting, Straight, 3/4" NPT Thread, 0.75" (25mm) Dia, NPB Metal, 10/pkg
Article Number
166-90536
Type
FSU25-075-C
Color
Metal (ML)
Features & Benefits
• Nickel plated brass compression fitting used with FSU, LFHU and FPU
flexible metallic conduit. • Fitting includes elastomeric sealing washer for IP65
ingress protection. • Suitable for knockouts or NPT / Metric threaded entries as
fitting rotates until tightened.
Quantity Per
pack
Product Description
Multipart straight compression fitting with fixed external thread pattern suitable
for threaded or knockout entries. Constructed with nickel plated brass
components that resist corrosion, ensures high mechanical strength and
electrical continuity. Fitting comprised of body, nut, grounding ferrule and nylon
compression seal. For use with FSU, FPU, and LFHU flexible metal conduits.
Short Description
Metallic Compression Fitting, Straight, 3/4" NPT Thread, 0.75" (25mm) Dia,
NPB Metal, 10/pkg
Global Part Name
FSU25-075-C-NPB/PA6-ML
Technical Description
Manufacturer Reference Number: FSU25-075-C
Length L (Imperial)
1.63
Length L (Metric)
41.5
Variant
Straight
Height H (Imperial)
1.04
Height H (Metric)
33.0
Nominal Diameter (Imperial)
3/4
Nominal Diameter (Metric)
25.0
Material
Polyamide 6 (PA6) Nickel Plated Brass (NPB)
Material Shortcut
NPB PA6
Halogen free
Yes
Operating Temperature (Metric)
-58°F to +275°F (-50°C to +135°C)
Reach Complaint(Article 33)
Yes
