Specification Sheet
Part Number:
FFE-1SSP
Fiber Façade Enclosure, 10–15 mm, SC-PC Simplex, With Adapters And Pigtails Installed, Black, 1/pkg
Article Number
904-01323
Type
FFE-1SSP-PC-BK
Color
Black (BK)
Features & Benefits
•
UV stable enclosure with IP55 (NEMA 4) sealing rating for long-term outdoor
performance. •
Detachable lid prevents access and can also be snapped back
to allow unrestricted access inside. •
Separation of inbound fiber from
connectorized drop cables keeps fragile areas protected. •
Pole or
building/façade mounted to provide connections where they are needed.
Quantity Per
EA
Product Description
The Fiber Façade Enclosure (FFE) features three separate areas to manage
inbound cable, fiber splices and drop cables (customer connection). The
inbound cable area has a dedicated entry port, supporting both cable end and
mid-span applications with loop storage capacity for up to 1.5 m of excess
fiber. The fiber splice area has capacity for a maximum of 24x heat shrink
splices and maintains positive fiber management (30 mm minimum bend
radius) throughout. The tray has a crossover facility that allows for alternative
routing requirements and a fiber storage capacity of 1.5 m for 250µm fiber and
1.0 m of 900µm fiber. A PLC splitter (60 mm x 7 mm x 4 mm) can be fitted on
the inside of the management area. The adapters are angled and spaced to
allow for inspection prior to connection. Eight included anchor guides secure
the drop cables (maximum diameter 6.0 mm). •
8x SC/LC Simplex or LC
Duplex customer connections. •
Two inbound/pass-thru and 8 Outbound SC or
LC Adapter ports support smaller MDU or SFU installations.
Short Description
Fiber Façade Enclosure, 10–15 mm, SC-PC Simplex, With Adapters And
Pigtails Installed, Black, 1/pkg
Global Part Name
FFE-1SSP-PC-BK-PC-BK
Port Count
8
Length L (Imperial)
9.5
Length L (Metric)
241.0
Variant
Outdoor Enclosure
Width W (Imperial)
6.1
Width W (Metric)
154.0
Height H (Imperial)
2.84
Height H (Metric)
72.0
Depth D (imperial)
2.84
