Specification Sheet
Part Number:
FEWM6
Wall Mount Fiber Enclosure, Unloaded, accepts 1 Adapter Panel, Black, 1/pkg
Article Number
904-00717
Type
FEWM6
Color
Black (BK)
Features & Benefits
• Durable stainless steel construction for long life. • Cable management spools
for effective slack management. • Bend radius control to minimize hand and
wrist strain. • Smooth grommet entry to protect cables from damage. • Locking
tab for added security. • Meet ANSI/TIA/EIA 568-C standards.
Quantity Per
box
Product Description
HellermannTyton wall mount fiber enclosures provide a secure termination
solution for applications requiring fully enclosed and/or lockable enclosures.
Wall mount enclosures accommodate up to 144 fibers, mount easily and
provide easy cable routing access behind the enclosure. Choose from
enclosure options to accommodate 1, 2 or 4 standard LGX adapter panels.
Short Description
Wall Mount Fiber Enclosure, Unloaded, accepts 1 Adapter Panel, Black, 1/pkg
Global Part Name
FEWM6-BK
Technical Description
Wall Mount Fiber Enclosure - Unloaded, accepts 1 Adapter Panel, Black
Port Count
24 6 12
Length L (Imperial)
1.5
Length L (Metric)
38.1
Variant
Wall mount
Width W (Imperial)
6.5
Width W (Metric)
165.1
Height H (Imperial)
7.0
Height H (Metric)
177.8
Material
Metal (MET)
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
Customs Number
8538907080
