Specification Sheet
Part Number:
FAP6DMMQLC
Fiber Adapter Panel Preloaded with 6 Duplex LC MM, Aqua, 1/pkg
Article Number
855-04230
Type
FAP6DMMQLC
Color
Aqua (AE)
Features & Benefits
• High performance zirconia ceramic ferrules allow for frequent, repeated
insertion. • Standard LC, SC, ST, MTP and MTRJ connector options to suit
specific applications. • “Snap lock” fixtures for easy and secure mounting. •
Meet ANSI/TIA/EIA 568-C standards. • Meet ANSI/TIA/EIA 604 (FOCIS)
connector interface requirements. • GSA compliant panels meet TAA
requirements for use in government projects.
Product Description
For customized wall mount and rack mount fiber optic enclosures,
HellermannTyton offers panel options featuring a variety of adapters to suit
different preferences and applications. In addition to adapter panels with
standard LC, SC, ST, MTP and MTRJ connections, HellermannTyton also
offers custom solutions. Our adapter panels include options to accommodate
OS1/2 in both standard and angled versions, as well as 62.5/125μm OM1,
50/125μm OM2 and 50/125μm 10 Gb OM3/4. HellermannTyton adapter panels
are made with zirconia ceramic or phosphor bronze ferrules for minimal
insertion loss contribution. Zirconia ceramic ferrules provided excellent
durability and are an ideal choice for use in laser optimized multimode and
single mode applications. HellermannTyton offers both standard and GSA
compliant adapter panels. GSA compliant panels meet Trade Agreement Act
(TAA) requirements, making them acceptable for use in US government
projects.
Short Description
Fiber Adapter Panel Preloaded with 6 Duplex LC MM, Aqua, 1/pkg
Global Part Name
FAP6DMMQLC
Technical Description
Adapter Panel Preloaded with 6 Duplex LC MM, Aqua
Port Count
12
Length L (Imperial)
5.09
Length L (Metric)
129.3
Width W (Imperial)
1.14
Width W (Metric)
28.96
Height H (Imperial)
1.14
Height H (Metric)
29.0
Depth D (imperial)
7.87
Depth D (metric)
200
