Specification Sheet
Part Number:
CL-LM30C-10
Cablelok LM30C 2 X 9.0 - 12.5 mm x 10, CR, Black, 1/pkg
Article Number
857-50208
Type
CABLELOK-LM30C-10
Color
Black (BK)
Features & Benefits
• Rapid installation requiring no specialized tools saves time and money. •
Highly repeatable – the quality of the seal is not dependent on the skill of the
engineer. • Tested beyond a 20-foot water head (58.8kPa), exhibiting excellent
sealing properties.
Quantity Per
bag
Product Description
HellermannTyton’s patented Cablelok mechanical seal enables fast, safe cable
installation, providing a repeatable and consistent seal between the cable and
the closure port with excellent non-leak performance. Installation times are
typically reduced by up to 90 percent.
Short Description
Cablelok LM30C 2 X 9.0 - 12.5 mm x 10, CR, Black, 1/pkg
Global Part Name
CABLELOK-LM30C-10
Technical Description
The LM Port Cablelok is a mechanical seal manufactured from Neoprene
rubber, Minlon and Acetal. There are 5 Cablelok's which cover a cable range
of 4.8mm – 15.0mm four of which have a dual outlet for loop through
applications, the fifth being a port plug for blocking unused LM sized drop
ports.
Port Count
2
Variant
Oval - LM
Material
Chloroprene Rubber (CR)
Material Shortcut
CR
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
10
Package Quantity (Metric)
10
Customs Number
9030400000
Content Unit(BMEcat)
pack
