Specification Sheet
Part Number:
CCE-1111A1-G
Customer Connection Enclosure, 1x LC/APC Duplex SM Adapter & Pigtail
Article Number
857-01450
Type
CCE-A11121A11/GY
Color
Gray (GY)
Features & Benefits
•
UV stable enclosure with IP54 (NEMA 3S) sealing rating for long-term outdoor
performance. •
Internal positive fiber management and fiber retention clips
maintain a minimum 30 mm bend radius throughout, ensuring reliable data
throughput. •
Hinged lid allows quick and clear access to internal fiber for
splicing and termination. •
CCE is same width as a brick blow-out cover to
mask any bricks damaged by drilling.
Quantity Per
EA
Product Description
The Customer Connection Enclosure (CCE) is designed as a Building Entry
Point (BEP) to provide a fiber termination and network demarcation point in a
Fiber to the Home (FTTH) network. A loop-through facility allows single fiber
elements to be removed and spliced while remaining fiber can be fed on to the
next connection point. A single port in the rear allows fiber to be passed
through the wall into the customer premises. Supplied cable ties secure all
incoming/outgoing cables and blown fiber ducts and provide strain relief where
necessary. The CCE can be supplied pre-loaded with fiber adapters and
pigtails as required. •
2x SC Simplex/LC Duplex customer connections •
4x heat
shrink splices •
6x incoming/outgoing ports and through-the-wall port •
Suitable
for cables or ducts up to a maximum diameter of 7 mm •
Store up to a
maximum of 50 m of 1.1 mm cable
Short Description
Customer Connection Enclosure, 1x LC/APC Duplex SM Adapter & Pigtail
Global Part Name
CCE-A11121A11/GY
Technical Description
The Customer Connection Enclosure (CCE) supports a maximum 2 x SC
Simplex or LC Duplex adaptors. The closure is manufactured from UV stable
ABS with a hinged lid which locks in the open position to allow for quick and
clear access to the internal fibre. The closure has 6 entry/exit ports at the
bottom of the closure which are suitable for cables and ducts up to a maximum
diameter of 8.5mm. A loop through facility allows for single fibre elements to
be removed and spliced whilst the remaining fibres can be fed on to the next
connection point. A single port in the rear of the closure allows for fibre to be
passed through the wall into the customer premises. Mechanical fixing is
provided to secure all incoming/outgoing cables/blown fibre ducts and to
provide strain relief where necessary. Internal positive fibre management and
fibre retention clips maintain a minimum 30mm bend radius throughout for up
to a maximum of 50m of 1.1mm diameter cable.
Variant
Outdoor FTTx Enclosures
Width W (Imperial)
5.12
Width W (Metric)
130
Height H (Imperial)
10.35
Height H (Metric)
263
Depth D (imperial)
1.46
