Specification Sheet
Part Number:
B-050-M20
Metallic Thread Converter, 1/2" NPT External Thread and M20 Internal Thread, NPB Metal, 10/pkg
Article Number
166-90421
Type
CNV-050-M20
Color
Metal (ML)
Features & Benefits
• Quickly converts metallic metric threads to NPT threaded fittings for use with
NPT threaded entries. • Achieve IP68 level ingress protection with use of
sealing washer.
Quantity Per
pack
Product Description
Nickel plated brass thread converter. Metric internal threads and NPT external
threads.
Short Description
Metallic Thread Converter, 1/2" NPT External Thread and M20 Internal Thread,
NPB Metal, 10/pkg
Global Part Name
CNV-050-M20-NPB-ML
Technical Description
Manufacturer Reference Number: B-050-M20
Length L (Imperial)
1.12
Length L (Metric)
28.5
Variant
Converter
Height H (Imperial)
0.94
Height H (Metric)
24.0
Nominal Diameter (Imperial)
1/2
Nominal Diameter (Metric)
20
Material
Nickel Plated Brass (NPB)
Material Shortcut
NPB
Operating Temperature (Metric)
-58°F to +572°F (-50°C to +300°C)
Package Quantity(Imperial)
10
Package Quantity (Metric)
10
