Specification Sheet
Part Number:
AT2060
AT2060 Auto Tool, Installs 30lb cable ties up to 1 1/4", Includes power supply and cords, 1/pkg
Article Number
103-00000
Type
AT2060
Color
Black (BK)
Features & Benefits
• Fast: Cable ties are installed quickly with one easy trigger depression,
increasing productivity while decreasing labor costs. • Reliable:
HellermannTyton's automatic cable tie systems have been tested to perform
extremely consistently, without interruption to workflow. • Ergonomic: The
ergonomic design of the automatic cable tie tool systems feature a comfortable
grip, low weight, and easy trigger depression to reduce installer effort and
strain while installing cable ties. • Providing Valuable Operator Feedback:
Equipped with a self diagnostic LCD information screen, the automatic cable
tie system easily guides the user through the cycles of cable tie installations. •
Flexible Manufacturing Versatility: HellermannTyton's cable tie tool systems
support principles of flexible manufacturing requirements and environments. •
Uniform Fastening Quality: HellermannTyton's automatic cable tie systems
feature adjustable tension control to deliver consistent levels of cable tie
fastening. • Range: HellermannTyton offers the widest range of automatic
cable tie tool systems which cover cable tie tensile strengths of 18, 30 and 50
pounds with bundle diameters between 1/16" to over 3".
Quantity Per
pcs.
Product Description
HellermannTyton's AT2060 system includes tool, power supply, power cord,
tool cord, and mantenance and operation manual. This system can be used in
handheld, bench mount, and overhead assembly configurations. The versatile
overhead assembly option provides the ultimate integration into the customer's
manufacturing area. HellermannTyton's autotool AT2060 is powered by a
standard 110 AC 27V electrical outlet that the power supply converts to a low
DC voltage for the tool.
Short Description
AT2060 Auto Tool, Installs 30lb cable ties up to 1 1/4", Includes power supply
and cords, 1/pkg
Global Part Name
AT2060-BK
Technical Description
AT2060 Auto Tool, Installs 30lb cable ties up to 1 1/4", Includes power supply
and cords
Length L (Imperial)
14.20
Length L (Metric)
361.2
Voltage Range
27 Volt
Width W (Imperial)
2.6
Width W (Metric)
66.4
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.50
Bundle Diameter Max (Imperial)
1.25
Bundle Diameter Max (Metric)
31.75
