HellermannTyton 596-96257 Specification Sheet

Specification Sheet
Part Number:
596-96257
Paint Mask Label, 2.0" X 1.5" X 4.375", 1 Across, Vinyl, White, 500/RL
596-96257
Type
PW2.75W2
Color
White (WH)
Features & Benefits
• Paint Mask Labels provide permanent paint protection but can still be
removed at any time when required. • Paint Mask Labels withstand chemicals
and heat to survive the painting process.
Quantity Per
roll
Product Description
HellermannTyton thermal transfer self-laminating Paint Mask Labels are
conformable with a white printable surface followed by a clear tail that
laminates the printed text when applied to a wire or cable. The labels utilize an
aggressive acrylic adhesive that allows the label to bond to large and small
diameter wires.
Short Description
Paint Mask Label, 2.0" X 1.5" X 4.375", 1 Across, Vinyl, White, 500/RL
Global Part Name
PW2.75W2-V-WH
Technical Description
Paint Mask Label, 2.0" X 1.5" X 4.375", 1 across, 2 piece design, .75" cable
diameter, Vinyl, White, 500/RL
Width W (Imperial)
2.0
Width W (Metric)
50.8
Bundle Diameter Min (Imperial)
.625
Bundle Diameter Min (Metric)
15.8
Bundle Diameter Max (Imperial)
.875
Bundle Diameter Max (Metric)
22.2
Thickness T (Metric)
64.0
Height H (Imperial)
1.5
Height H (Metric)
38.1
Width of Liner (Metric)
106.6
Width of Liner (imperial)
4.2
Material
Vinyl
Material Shortcut
V
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-51°F to +200°F (-46°C to +93°C)
Operating Temperature (Metric)
-40°F to +194°F (-40°C to +90°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
UL-Recognized
UL Recognized (US)
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
0.68
Weight (Imperial)
1.48
