HellermannTyton 596-73833 Specification Sheet

Specification Sheet
Part Number:
596-73833
Thermal Transfer Labels, High-Bond Adhesive, 2.0" x 1.0", Polyester, White, 3000/roll
596-73833
Type
PCP2X1
Color
White (WH)
Features & Benefits
White polyester is glossy, allowing for the highest resolution and print contrast.
The acrylic-based adhesive bonds to a wide variety of substrates and can
withstand high temperatures long term. •
The printable surface is highly
resistant to chemicals and solvents and can withstand long-term UV exposure.
Quantity Per
roll
Product Description
For the ultimate in chemical and solvent resistance and long term outdoor
durability, the 840 white polyester offers the most aggressive performance
features of any other polyester label material. With an initial outdoor life of 7
years, the labels have been tested far beyond the published limits and the
acrylic adhesive bonds well to powder coat painted surfaces as well as baked
enamel and slightly textured substrates.
Short Description
Thermal Transfer Labels, High-Bond Adhesive, 2.0" x 1.0", Polyester, White,
3000/roll
Global Part Name
PCP2X1-840W-WH
Width W (Imperial)
2.0
Width W (Metric)
50.8
Thickness T (Metric)
64.0
Height H (Imperial)
1.0
Height H (Metric)
25.4
Width of Liner (Metric)
122.9
Width of Liner (imperial)
2.2
Material
Type 840W, Polyester (PET), White (WH)
Material Shortcut
840W
Adhesive
High Bond Acrylic
Halogen free
No
Adhesive Operating Temperature
-40°F to +302°F (-40°C to +150°C)
Operating Temperature (Metric)
-40°F to +300°F (-40°C to +149°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
CSA 66956
UL Recognized (US)
Yes
Package Quantity(Imperial)
3000
Package Quantity (Metric)
3000
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
0.68
Weight (Imperial)
1.48
