Specification Sheet
Part Number:
596-00905
Article Number
596-00905
Type
AF5X35W
Color
Orange (OG)
Features & Benefits
• Made with UV stable inks and materials for durability and weather resistance
• Supplied with aggresive adhesive to ensure long life • Meets NEC & IFC
standards for printed text, character height, color and outdoor UV stability to
pass inspections • Pre-printed labels offer significant time and cost savings
over high priced engraved and lead time purchased markers
Quantity Per
pack
Product Description
HellermannTyton pre-printed Solar Installation labels are designed to meet the
requirements of the 2014 National Electrical Code (NEC 2011) and the 2012
International Fire Code (IFC 2012) as well as being acceptable to the Authority
Having Jurisdiction (AHJ). Labels are made with durable UV stable materials
and adhesives that are designed to stick to both baked enamel and powder
coat surfaces. Where applicable, labels are made using reflective materials for
first responder safety. Some pre-printed labels are printable using a thermal
transfer printer when variable voltage or series data must be printed and
displayed.
Short Description
Arc Flash Label, WARNING ARC FLASH AND SHOCK HAZARD, 5.0" x 3.75",
PET, Orange/White, 10/pkg
Global Part Name
AF5X35W-840/926-OG
Technical Description
Arc Flash Label, Warning- Arc Flash and Shock Hazard, 5.0" X
3.75",Orange/White
Width W (Imperial)
5.00
Width W (Metric)
127
Thickness T (Metric)
64.0
Height H (Imperial)
3.75
Height H (Metric)
95.25
Material
Type 840/926, Polyester (PET), UV stable, clear Polyester laminate
Material Shortcut
840/926
Adhesive
Acrylic
