Specification Sheet
Part Number:
596-00881
Solar Label, Printable, 2020 Code, Maximum Voltage, 3.75" x 2.12", PET, Red, 10/pkg
Article Number
596-00881
Type
DC201710
Color
Red (RD)
Features & Benefits
• Made with UV-stable inks and materials for durability and weather resistance.
• Aggressive adhesive ensures long life. • Meets NEC and IFC standards for
printed text, character height, color and outdoor UV stability to pass
inspections. • Pre-printed labels offer significant time and cost savings over
high-priced plastic engraved phenolic placards and lead time purchased
markers.
Quantity Per
pack
Product Description
HellermannTyton Pre-Printed Vinyl Solar Installation Labels are designed to
meet the requirements of the National Electrical Code and the International
Fire Code as well as being acceptable to the Authority Having Jurisdiction
(AHJ). Labels are made with durable UV-stable materials and adhesives
designed to adhere to both baked enamel and powder coated surfaces. Where
applicable, labels are made using reflective materials for first responder safety.
Some pre-printed labels are printable using a thermal transfer printer when
variable voltage or series data must be printed and displayed.
Short Description
Solar Label, Printable, 2020 Code, Maximum Voltage, 3.75" x 2.12", PET, Red,
10/pkg
Global Part Name
DC201710-840/926-RD
Technical Description
Printable Solar Label-2017 Code, Maximum Voltage Label, 3.75" X 2.12",
Polyester, Red, 10/pkg
Width W (Imperial)
3.75
Width W (Metric)
95.25
Thickness T (Imperial)
0.0025
Thickness T (Metric)
64.0
Height H (Imperial)
2.12
Height H (Metric)
53.80
Width of Liner (Metric)
98.29
Width of Liner (imperial)
3.87
Material
Type 840/926, Polyester (PET), UV stable, clear Polyester laminate
Material Shortcut
840/926
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-40°F to +302°F (-40°C to +150°C)
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
CSA 66956 NEC2017 UL 969
Warranty (US)
Yes
UL Recognized (US)
Yes
Package Quantity(Imperial)
10
Package Quantity (Metric)
10
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
Weight (Metric)
0.521
Weight (Imperial)
1.14
