Page 1
Specification Sheet
Part Number:
596-00865
Metal Solar Placard, Engravable, DC Rating Label, 4.0" x 2.0", AL, Black, 5/pkg
Article Number
596-00865
Type
DCRATINGM5ENG
Color
Black (BK)
Features & Benefits
• Placards made with UV stable inks and materials tested to last up to 25
years, even in direct sun exposure. • Aggressive adhesive ensures strong
bond, even on powder coated surfaces. • Meets or exceeds NEC & IFC
standards for printed text, character height, color and outdoor UV stability. •
Optional Paint Shields provide additional protection for pre-printed and variable
data placards.
Quantity Per
pcs.
Page 2
Product Description
Variable data placards are used to mark areas specific to the individual
installation, like voltage data. Made of the same durable material as pre-printed
metal solar placards, HellermannTyton offers two styles of variable placards:
hand-writable and engravable. Both hand-writable placards feature a silver
variable data area that can be marked using an industrial paint pen.
Engravable placards have a black area that can be engraved using standard
engraving equipment.
Short Description
Metal Solar Placard, Engravable, DC Rating Label, 4.0" x 2.0", AL, Black,
5/pkg
Global Part Name
DCRATINGM5ENG-AA-BK
Technical Description
Pre-Printed Metal Solar Placard, 2008 DC Rating Label for engraving", 4.0" X
2.00", Black
Local Order Number 2
Cross Reference = Paint Shield: 596-00794
Length L (Imperial)
2.00
Length L (Metric)
50.8
Width W (Imperial)
4.0
Width W (Metric)
101.6
Height H (Imperial)
2.0
Height H (Metric)
50.80
Material
Anodized Aluminum (AA)
Material Shortcut
AA
Page 3
Adhesive
Ultra High Bond Permanent Acrylic Adhesive
Halogen free
No
Adhesive Operating Temperature
from +50°F (from +10°C)
Operating Temperature (Metric)
-40°F to +203°F (-40°C to +95°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
NEC2014
Warranty (US)
Yes
Package Quantity(Imperial)
5
Package Quantity (Metric)
5
Customs Number
3919905060
Labels per Column
1
Labels per Row
1
Weight (Metric)
.104
Weight (Imperial)
0.23
