Page 1
Specification Sheet
Part Number:
596-00857
Metal Solar Placard, Engravable, 2017 Code, PHOTOVOLTAIC AC DISCONNECT, 3.75"x1.0", AL, Black,
5/pkg
Article Number
596-00857
Type
ACDISCTM5ENG
Color
Black (BK)
Features & Benefits
• Placards made with UV stable inks and materials tested to last up to 25
years, even in direct sun exposure. • Aggressive adhesive ensures strong
bond, even on powder coated surfaces. • Meets or exceeds NEC & IFC
standards for printed text, character height, color and outdoor UV stability. •
Optional Paint Shields provide additional protection for pre-printed and variable
data placards.
Quantity Per
pack
Page 2
Product Description
Variable data placards are used to mark areas specific to the individual
installation, like voltage data. Made of the same durable material as pre-printed
metal solar placards, HellermannTyton offers two styles of variable placards:
hand-writable and engravable. Both hand-writable placards feature a silver
variable data area that can be marked using an industrial paint pen.
Engravable placards have a black area that can be engraved using standard
engraving equipment.
Short Description
Metal Solar Placard, Engravable, 2017 Code, PHOTOVOLTAIC AC
DISCONNECT, 3.75"x1.0", AL, Black, 5/pkg
Global Part Name
ACDISCTM5ENG-AA-BK
Technical Description
3.75" X 1" Black text on aluminum background that reads as:
"PHOTOVOLTAIC AC DISCONNECT." - 10 per pack. Nameplate can be used
with standard engraving equipment to add variable data.
Local Order Number 2
Cross Reference = Paint Shield: 596-00796
Length L (Imperial)
3.75
Length L (Metric)
95.25
Width W (Imperial)
3.75
Width W (Metric)
92.25
Height H (Imperial)
1.0
Height H (Metric)
25.40
Material
Anodized Aluminum (AA)
Page 3
Material Shortcut
AA
Adhesive
Ultra High Bond Permanent Acrylic Adhesive
Halogen free
No
Adhesive Operating Temperature
from +50°F (from +10°C)
Operating Temperature (Metric)
-40°F to +203°F (-40°C to +95°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
NEC2014 NEC2017
Warranty (US)
Yes
Package Quantity(Imperial)
5
Package Quantity (Metric)
5
Customs Number
7616995195
Labels per Column
1
Labels per Row
1
Weight (Metric)
.104
Weight (Imperial)
0.23
Page 4
