Specification Sheet
Part Number:
596-00405
Foam Nameplate, 1.2" x 1.5" Button Label With .88" Hole, PET, Yellow, 250/roll
Article Number
596-00405
Type
NPLH31X38YE22.5
Color
Yellow (YE)
Features & Benefits
• Foam Nameplate labels are less costly than plastic or metal engraved plates,
saving material costs. • Foam Nameplate labels conform to textured and other
low energy surfaces ensuring the labels stay in place for the life of the product.
• Labels are UV and chemical resistant for long life in an industrial
environment. • Foam nameplate labels are printable using a thermal transfer
printer for complete control and on-demand creation of labels.
Quantity Per
roll
Product Description
Foam Nameplate labels are designed to replace plastic and metal engraved
phenolic plates commonly found on electrical control panels. The labels
provide the look and feel of a plastic engraved or metal plate, but at a fraction
of the cost. Labels can be printed using HellermannTyton Tagprint Pro labeling
software and can include printed logos, barcodes and text of almost any size
and type.
Short Description
Foam Nameplate, 1.2" x 1.5" Button Label With .88" Hole, PET, Yellow, 250/roll
Global Part Name
NPLH31X38YE22.5-PET-YE
Technical Description
Foam Nameplate, 1.2" X 1.5" Button Label With .88" Hole, PET, Yellow
Width W (Imperial)
1.2
Width W (Metric)
30.5
Height H (Imperial)
1.50
Height H (Metric)
38.10
Width of Liner (Metric)
36.83
Width of Liner (imperial)
1.45
Mounting Hole Diameter D (Imperial)
0.88
Mounting Hole Diameter D (Metric)
22.35 mm
Mounting Hole Diameter D Max (Metric)
22.35
