Specification Sheet
Part Number:
596-00387
Pre-Printed Header Label, DANGER, Blank Symbol Panel, 1.35" x 2.75", PET, Red, 250/roll
Article Number
596-00387
Type
DS275X135
Color
Red (RD)
Features & Benefits
• Pre-Printed Signal Word labels come with the header pre-printed in colors so
that only one color of ribbon is needed to complete the message panel. •
Labels are pre-made to the most recent ANSI standards so that code
compiance is assured. • Pre-Printed Signal Panel labels can be printed using
standard thermal transfer printers to reduce labor, eliminate minimum orders
and allow the user to create labels on demand when needed.
Quantity Per
roll
Product Description
Pre-Printed Signal Word Labels come pre-printed with WARNING, NOTICE,
CAUTION, DANGER and SAFETY headers in orange, blue, yellow, red and
green as defined by ANSI Z535. The variable body text can be printed using
TagPrint Pro labeling software and the HellermannTyton line of thermal transfer
printers or any standard thermal transfer printer. Only one color needs to be
printed to complete the label, saving time and money.
Short Description
Pre-Printed Header Label, DANGER, Blank Symbol Panel, 1.35" x 2.75", PET,
Red, 250/roll
Global Part Name
DS275X135-PET-RD
Technical Description
Pre-Printed Header Label, DANGER, Blank symbol panel, 1.35" X 2.75", Red
Width W (Imperial)
1.35
Width W (Metric)
34.29
Thickness T (Metric)
64.0
Height H (Imperial)
2.75
Height H (Metric)
69.85
Width of Liner (Metric)
35.56
Width of Liner (imperial)
1.40
Material
Polyester (PET)
Material Shortcut
PET
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-40°F to +302°F (-40°C to +150°C)
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
UL Recognized (US)
Yes
Package Quantity(Imperial)
250
Package Quantity (Metric)
250
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
Weight (Metric)
0.521
Weight (Imperial)
1.14
