Specification Sheet
Part Number:
596-00383
Phase label, 1" x .5", PET, Black, 2500/roll
Article Number
596-00383
Type
PLB3P
Color
Black (BK)
Features & Benefits
•
Thermal transfer labels are made with high-performance materials for
long-term industrial applications. •
Labels can be printed in any standard
thermal transfer printer giving the user options for printing and eliminating the
need to be dedicated to one printer model. •
The labels are available in a wide
variety of sizes so that finding a label for a particular application is easy.
Quantity Per
roll
Product Description
Phase labels are microperforated between each label so that it can be applied
as one strip to the panel or broken into individual labels.
Short Description
Phase label, 1" x .5", PET, Black, 2500/roll
Global Part Name
PLB3P-PET-BK
Technical Description
Phase label, 1" X .5", PET, Black
Local Order Number 2
596-00383
Width W (Imperial)
1.0
Width W (Metric)
25.4
Thickness T (Metric)
64.0
Height H (Imperial)
0.5
Height H (Metric)
12.7
Width of Liner (Metric)
85.09
Width of Liner (imperial)
3.35
Material
Polyester (PET)
Material Shortcut
PET
Adhesive
Acrylic
Halogen free
No
Operating Temperature (Metric)
-40°F to +300°F (-40°C to +149°C)
