Specification Sheet
Part Number:
596-00241
Solar Label, Printable, DC Rating, 3.75" x 2.0", PET, Red, 50/roll
Article Number
596-00241
Type
DCRATING
Color
Red (RD)
Features & Benefits
• Made with UV-stable inks and materials for durability and weather resistance.
• Polyester is resistant to chemicals and solvents and will remain legible in
dirty environments. • High abrasion and scuff resistance for high-performance
labeling. • Meets NEC & IFC standards for printed text, character height, color
and outdoor UV stability to pass inspections.
Quantity Per
roll
Product Description
HellermannTyton pre-printed Solar Rating labels are designed to meet the
requirements of the National Electrical Code and the International Fire Code as
well as being acceptable to the Authority Having Jurisdiction (AHJ). Labels are
made with durable UV-stable materials and adhesives that are designed to
stick to both baked enamel and powder coat surfaces. Where applicable,
labels are made using reflective materials for first responder safety. Some
pre-printed labels are printable using a thermal transfer printer when variable
voltage or series data must be printed and displayed.
Short Description
Solar Label, Printable, DC Rating, 3.75" x 2.0", PET, Red, 50/roll
Global Part Name
DCRATING-840/926-RD
Technical Description
Printable Solar Label, DC Ratings (Operating Current, Voltage; Max Voltage;
Short Circuit Current), 3.75" X 2.0", Red
Local Order Number 2
Cross Reference = 10 per pack: 596-00851; Printable Metal Solar Placard 5
pack: 596-00864; Engravable Metal Solar Placard 5 pack: 596-00865
Width W (Imperial)
3.75
Width W (Metric)
92.25
Thickness T (Metric)
64.0
Height H (Imperial)
2.0
Height H (Metric)
50.80
Material
Type 840/926, Polyester (PET), UV stable, clear Polyester laminate
Material Shortcut
840/926
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-40°F to +302°F (-40°C to +150°C)
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
IFC 2012 CSA 66956 UL 969 NEC2011
Warranty (US)
Yes
UL Recognized (US)
Yes
Package Quantity(Imperial)
50
Package Quantity (Metric)
50
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
Weight (Metric)
0.521
Weight (Imperial)
1.14
