Specification Sheet
Part Number:
596-00204
Article Number
596-00204
Type
4X6NOTICE
Color
Blue (BU)
Features & Benefits
• Pre-Printed Solar Labels are made with UV-stable inks and materials for
durability and weather resistance. • Polyester is resistant to chemicals and
solvents and will remain legible in dirty environments. • High abrasion and
scuff resistance for high performance labeling. • Meets NEC & IFC standards
for printed text, character height, color and outdoor UV stability to pass
inspections.
Quantity Per
roll
Product Description
HellermannTyton Pre-Printed Solar Installation Labels are designed to meet
the requirements of the National Electrical Code and the International Fire
Code as well as being acceptable to the Authority Having Jurisdiction (AHJ).
Labels are made with durable UV stable materials and adhesives that are
designed to stick to both baked enamel and powder coat surfaces. Where
applicable, labels are made using reflective materials for first responder safety.
Some pre-printed labels are printable using a thermal transfer printer when
variable voltage or series data must be printed and displayed.
Short Description
Pre-Printed Header Label NOTICE, 6.0" x 4.0", PET, Blue, 250/roll
Global Part Name
4X6NOTICE-PET-BU
Technical Description
Pre-Printed Header Label, NOTICE, 4" X 6", Blue
Width W (Imperial)
6.0
Width W (Metric)
152.4
Thickness T (Metric)
64.0
Height H (Imperial)
4.0
Height H (Metric)
101.6
Width of Liner (Metric)
106.6
Width of Liner (imperial)
4.2
Material
Polyester (PET)
Material Shortcut
PET
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-40°F to +302°F (-40°C to +150°C)
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
UL Recognized (US)
Yes
Package Quantity(Imperial)
250
Package Quantity (Metric)
250
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
Weight (Metric)
0.521
Weight (Imperial)
31.97
