Specification Sheet
Part Number:
558-00503
Adhesive Labels, Solid Color Continuous Roll, Reflective, 3.0" x 100', UV Stable PET, Red, 100 ft/roll
Article Number
558-00503
Type
HT3RDHB250
Color
Red (RD)
Features & Benefits
• Continuous Polyester Labels are made with UV stable materials for long
outdoor life. • Labels use UV stable permanent ink. • Continuous polyester is
provided in continuous rolls so that the markers can be printed and cut to any
length using HellermannTyton thermal trasnfer printing systems.
Quantity Per
roll
Product Description
Continuous Polyester Labels are made with UV stable materials for long
outdoor life. The labels are made with UV stable permanent inks for long term
fade resistance. The Continuous Polyester is provided in continuous rolls so
that the markers can be printed and cut to any length using HellermannTyton
thermal transfer printing systems.
Short Description
Adhesive Labels, Solid Color Continuous Roll, Reflective, 3.0" x 100', UV
Stable PET, Red, 100 ft/roll
Global Part Name
HT3RDHB250-840/926-RD
Technical Description
Solid Colored Continuous Roll, Reflective, 3.0" X 100', Red
Length L (Imperial)
100.0
Length L (Metric)
30.48
Variant
3.2mil, 50lb bleached kraft paper
Width W (Imperial)
3.0
Width W (Metric)
76.2
Width of Liner (Metric)
76.2
Width of Liner (imperial)
3.0
Material
Type 840/926, Polyester (PET), UV stable, clear Polyester laminate
Material Shortcut
840/926
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-40°F to +302°F (-40°C to +150°C)
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
IFC 2012 UL 969 CSA 66956 NEC2011 NEC2014 ANSI Standard Z535.4
UL Recognized (US)
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
30.48
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
Weight (Metric)
0.544
Weight (Imperial)
1.199
