Specification Sheet
Part Number:
558-00382
Adhesive Labels, Banded Color Continuous Roll, 4.0" x 250', UV Stable, Orange/White, 250 ft/roll
Article Number
558-00382
Type
HT4OE10250UV
Color
Orange (OG)
Features & Benefits
• Continuous Colored Signal Panel labels come with yellow or orange stripes
for easy printing of caution and warning labels. • Continuous labels allow for
designing and cutting labels to any length. • Various widths are available so
that a wide variety of sign sizes can be customized and produced on demand.
Quantity Per
roll
Product Description
The Pre-printed colored header vinyl rolls can be used to design signs that
conform to Occupational Safety and Hazard Association (OSHA) and American
National Standards Insitute (ANSI) requirements for Warning and Caution
Signs and markers. All can be designed, printed and cut to length in Tagprint
Pro and any HellermannTyton thermal transfer printing system.
Short Description
Adhesive Labels, Banded Color Continuous Roll, 4.0" x 250', UV Stable,
Orange/White, 250 ft/roll
Global Part Name
HT4OE10250UV-840/926-OG
Technical Description
Banded Continuous Colored Signal Panel Roll, 4.0" X 250', UV Stable,
Orange/White
Length L (Imperial)
250.0
Length L (Metric)
76.2
Variant
3.2mil, 50lb bleached kraft paper
Width W (Imperial)
4.0
Width W (Metric)
101.6
Thickness T (Metric)
64.0
Width of Liner (Metric)
101.6
Width of Liner (imperial)
4.0
Material
Type 840/926, Polyester (PET), UV stable, clear Polyester laminate
Material Shortcut
840/926
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-40°F to +302°F (-40°C to +150°C)
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
UL 969 IFC 2012 NEC2014 CSA 66956 NEC2011 ANSI Standard Z535.4
Package Quantity(Imperial)
250
Package Quantity (Metric)
76.20
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
Weight (Metric)
1.176
Weight (Imperial)
2.57
