Page 1
Specification Sheet
Part Number:
556-04041
Print Head for Thermal Transfer Printer, Gray, 1/ea
Article Number
556-04041
Type
TT4030 Printhead
Color
Gray (GY)
Features & Benefits
• Premium-quality TT4030 printer is designed for medium- and heavy-duty
industrial applications. • Print accuracy, consistency, speed, and power are
best in class. • 300 dpi print head fulfils all standard requirements for printing
bar codes, warning signs, logos, and written information. • Easily prints
high-definition graphics such as 2D barcodes, standard bar codes, numbers,
and text on adhesive labels, thermo plastics such as heat shrink and Tiptags. •
Print speeds up to 300 mm per second are possible dependent on the material
you wish to print. • Standard adjustments are carried out with the on-board tool
and this ensures operator down time is kept to a minimum. • The exceptionally
durable print head is of the highest quality and as such has a warranty of 24
months or 50 km (whichever comes first) in thermal transfer mode. • Optional
premium quality accessories are designed to work seamlessly with the printer
and will suit the most demanding needs.
Quantity Per
bag
Page 2
Product Description
Thermal Transfer Printing Systems are designed to work flawlessly with
HellermannTyton Tagprint Pro label printing software. The printers are durable
and designed for high-volume, industrial-grade printing in a wide variety of
working environments.
Short Description
Print Head for Thermal Transfer Printer, Gray, 1/ea
Global Part Name
TT4030 Printhead-DIV-GY
Technical Description
TT4030 Printhead 4.3/300
Length L (Imperial)
1.0
Length L (Metric)
25.4
Width W (Imperial)
4.0
Width W (Metric)
101.6
Height H (Imperial)
0.25
Height H (Metric)
6.35
Material
Various (DIV)
Material Shortcut
DIV
Halogen free
Yes
Operating Temperature (Metric)
+40°F to +104°F (+4°C to +40°C)
Page 3
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
Customs Number
8443913000
Content Unit(BMEcat)
pcs.
Weight (Metric)
0.01
Weight (Imperial)
0.022
