Specification Sheet
Part Number:
556-00430
TTM430 Thermal Transfer Printer, 300 dpi, Gray, 1/pkg
Article Number
556-00430
Type
TTM430
Color
Gray (GY)
Features & Benefits
• 300 dpi print head for high resolution printing. • Ethernet ready for easy
network connectivity. • Print speeds up to 7.87 in / second for fast label
production. • Adjustable gap sensor so that the printer can detect a wide
variety of label types. • Floating print head to automatically adjust to varying
media thickness such as printable heat shrink tubing. • Optional cutter
faceplate for automatic cutting and kitting of printed labels. • Wireless network
ready for full production control. • LCD touch screen for easy reference of
network status, date, time, print head temperature and ribbon usage.
Quantity Per
EA
Product Description
HellermannTyton's TTM430 and TTM460 Series thermal transfer printers are
designed for medium- to high-volume users of thermal transfer labels and
ShrinkTrak. Their user-friendly design features a streamlined menu for simple
navigation, while the built-in caddy allows even the largest label rolls to fit
inside. The optional cutter can cut through the thickest material. The TTM430's
300 dpi print head delivers excellent results and the TTM460's 600 DPI print
head provides the highest quality printing available. These printers handle all
sizes of HellermannTyton's ShrinkTrak markers and can print on even the
smallest labels.
Short Description
TTM430 Thermal Transfer Printer, 300 dpi, Gray, 1/pkg
Global Part Name
TTM430-PL-GY
Technical Description
Thermal Transfer Printer, TTM430, 300 DPI, Gray
Length L (Imperial)
16.0
Length L (Metric)
406.4
Width W (Imperial)
9.4
Width W (Metric)
240
Height H (Imperial)
12.28
Height H (Metric)
312
Depth D (imperial)
17.1
Depth D (metric)
435
Material
Plastic (PL)
