Specification Sheet
Part Number:
553-50181
ShrinkTrak Labels, 1-Sided, 4-Slit, .125" (3.17mm), PO-X, Black, 1000/box
Article Number
553-50181
Type
HST3-1BK-3S
Color
Black (BK)
Features & Benefits
• Slide Slit and optional center slits for easy wire insertion. • Smooth surface
for clean and legible printing. • Supplied on a ladder style carrier so that
markers can be kitted after printing. • A 3:1 shrink ratio means fewer skews as
each marker covers a wider range of wire diameters.
Quantity Per
reel
Product Description
HellermannTyton's ShrinkTrak heat shrinkable markers make it easy to mark
wire, cable and other components. The military approved heat shrink tubing is
flattened and assembled in a ladder style carrier system for easy printing using
a thermal transfer printer. The ladder system creates a kit of markers that can
be sorted, removed and applied in any order thus saving time, labor and
speeding production.
Short Description
ShrinkTrak Labels, 1-Sided, 4-Slit, .125" (3.17mm), PO-X, Black, 1000/box
Global Part Name
HST3-1BK-3S-PO-X-BK
Variant
Thin-Wall
Width W (Imperial)
0.475
Width W (Metric)
12.07
Thickness T (Imperial)
.003
Thickness T (Metric)
.0762
Height H (Imperial)
1.9
Height H (Metric)
48.3
Width of Liner (Metric)
76.2
Width of Liner (imperial)
3.0
Outside Diameter OD(Imperial)
0.125
Outside Diameter OD(metric)
3.2
Outside Diameter Max(Imperial)
0.125
Outside Diameter Max (metric)
3.2
Wall Thickness WT (Imperial)
0.031
Wall Thickness WT (Metric)
0.79
Material
Polyolefin, cross-linked (PO-X)
Material Shortcut
PO-X
US MIL SPEC
SAE-AMS-DTL-23053/5 Class 1 and 3
SAE-AS81531
MIL-STD-202G Method 215K
Flammability
UL 224 VW-1
Halogen free
No
Operating Temperature (Metric)
-67°F to +275°F (-55°C to +135°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
UL 224 125 °C 600V VW-1
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Content Unit(BMEcat)
pack
Weight (Metric)
0.294
Weight (Imperial)
12.07
