Page 1
Specification Sheet
Part Number:
544-80101
M-Boss Marker, 1.77" Wide x 0.39" High, Stainless Steel, Silver, 1000/Box
Article Number
544-80101
Type
MBML10X45
Color
Metal (ML)
Features & Benefits
• Raised marking ensure text visibility even when covered in dust, debris,
grease and oil. • Stainless steel grade SS316 is suited for use in harsh
environments. • Marker plates are designed for use with stainless steel cable
ties with a 0.81" (4.6mm) strap width.
Quantity Per
box
Product Description
M-Boss Compact is quiet, easy to use metal plate embossing printer with a
small production footprint. It is simple to install and operate only needs a
standard electrical supply and a PC. Marker plates are attached to pipes and
cables using 4.6mm width MBT cable ties and a MK9SST hand tool.
Short Description
M-Boss Marker, 1.77" Wide x 0.39" High, Stainless Steel, Silver, 1000/Box
Page 2
Global Part Name
MBML10X45-SS316-ML
Technical Description
M-Boss Marker, .39" Wide X 1.77" Long, Silver
Length L (Metric)
44.5
Fixation Method
Others
Variant
Other
Width W (Imperial)
1.77
Width W (Metric)
10.0
Height H (Imperial)
0.39
Height H (Metric)
9.91
Diameter D (imperial)
0.236
Diameter D (metric)
6
Cable Tie Width Max (Imperial)
0.18
Cable Tie Width Max (Metric)
4.6
Bolt Size
MBT Metal ties max width 4.6 mm
Material
Stainless Steel (SS316)
Page 3
Material Shortcut
SS316
Halogen free
Yes
Operating Temperature (Metric)
-112°F to +1000°F (-80°C to +538°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
7326908695
Content Unit(BMEcat)
pcs.
Weight (Metric)
2.98
Weight (Imperial)
6.569
