Specification Sheet
Part Number:
4FRP0C
Spiralwrap Protective Sheathing, .75" Diameter, PE-FR, Black, 100 ft/roll
Article Number
161-05057
Type
4FRP
Color
Black (BK)
Features & Benefits
• Sheathing allows flexible routing and lead-out of cables • The inner edges
are beveled preventing damage to cables • Sheathing is reusable and resistant
to most chemicals • Spiralwrap is U.L. Recognized
Quantity Per
reel
Product Description
HellermannTyton’s Spiralwrap protective sheathing provides cable protection
and flexible routing. Spiralwrap is wrapped around a group of cables to shield
and organize.
Short Description
Spiralwrap Protective Sheathing, .75" Diameter, PE-FR, Black, 100 ft/roll
Global Part Name
4FRP-PE-FR-BK
Length L (Imperial)
100.0
Length L (Metric)
30.48
Variant
Spiral Binding
Bundle Diameter Min (Imperial)
0.75
Bundle Diameter Min (Metric)
19.05
Bundle Diameter Max (Imperial)
5.0
Bundle Diameter Max (Metric)
127.0
Diameter D (imperial)
0.75
Diameter D (metric)
19.05
Nominal Diameter (Imperial)
3/4
Nominal Diameter (Metric)
19.05
Wall Thickness WT (Imperial)
.065
Wall Thickness WT (Metric)
1.65
Material
Polyethylene, flame retardant (PE-FR)
