HellermannTyton 422-30512 Specification Sheet

Specification Sheet
Part Number:
422-30512
Heat Shrink Molded Shapes, Long-Tail Right-Angle Boot, 333F332-8, PEEX, BK, 5/bag
422-30512
Type
333F332-8
Color
Black (BK)
Features & Benefits
• Connector strain relief for small cable diameters requiring high shrink ratio.
Quantity Per
bag
Product Description
Helashrink 313C series is used with a circular grooved adapter to provide
strain relief and if adhesive is used, excellent environmental sealing can be
achieved. The convoluted design provides the flexibility to accommodate
different cable outlet angles.
Short Description
Heat Shrink Molded Shapes, Long-Tail Right-Angle Boot, 333F332-8, PEEX,
BK, 5/bag
Global Part Name
333F332-8-PEEX-BK
Variant
For plug
Material
Polyester elastomer cross-linked (PEEX)
Material Shortcut
PEEX
Flammability
ASTM D635
Operating Temperature (Metric)
-67°F to +248°F (-55°C to +120°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
5
Package Quantity (Metric)
5
