Specification Sheet
Part Number:
418-20001
Heat Shrink Molded Shapes, 1800 Series Angle with Rib, 1820-4-G, PO-X, BK, 1/bag
Article Number
418-20001
Type
1820-4-G
Color
Black (BK)
Features & Benefits
• Provides strain relief and mechanical protection for harness systems. • Use in
conjunction with a circular grooved adaptor.
Quantity Per
bag
Product Description
Helashrink 1800 series, with rib, provides strain relief and mechanical
protection for harness systems when used in conjunction with a circular
grooved adaptor. Can be supplied in a range of nominal recovered angles and
material / adhesive combinations to suit most applications.
Short Description
Heat Shrink Molded Shapes, 1800 Series Angle with Rib, 1820-4-G, PO-X, BK,
1/bag
Global Part Name
1820-4-G-PO-X-BK
Material
Polyolefin, cross-linked (PO-X)
Material Shortcut
PO-X
Flammability
ASTM D635
Operating Temperature (Metric)
-103°F to +302°F (-75°C to +150°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
