Specification Sheet
Part Number:
411-26023
Heat Shrink Molded Shapes, Series 90-Degree Low-Profile with Rib,1126-1-G, PO-X, BK, 1/bag
Article Number
411-26023
Type
1126-1-G
Color
Black (BK)
Features & Benefits
• Lightweight, low profile, compact strain relief and mechanical protection. •
Typically used on airborne harnesses.
Quantity Per
bag
Product Description
Helashrink 1100 series, VG style/MIL style, is typically used on airborne
harnesses to achieve light weight, low profile, compact strain relief and
mechanical protection.
Short Description
Heat Shrink Molded Shapes, Series 90-Degree Low-Profile with Rib,1126-1-G,
PO-X, BK, 1/bag
Global Part Name
1126-1-G-PO-X-BK
Variant
For plug
Material
Polyolefin, cross-linked (PO-X)
Material Shortcut
PO-X
Flammability
ASTM D635
Operating Temperature (Metric)
-103°F to +302°F (-75°C to +150°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
