Specification Sheet
Part Number:
2.5NFP0C
Spiralwrap Protective Sheathing, .38" Diameter, PE, Black, 100 ft/roll
Article Number
161-05024
Type
2.5NFP
Color
Black (BK)
Features & Benefits
• Sheathing allows flexible routing and lead-out of cables • The inner edges
are beveled preventing damage to cables • Sheathing is reusable and resistant
to most chemicals • Spiralwrap is U.L. Recognized
Quantity Per
reel
Product Description
HellermannTyton’s Spiralwrap protective sheathing provides cable protection
and flexible routing. Spiralwrap is wrapped around a group of cables to shield
and organize.
Short Description
Spiralwrap Protective Sheathing, .38" Diameter, PE, Black, 100 ft/roll
Global Part Name
2.5NFP-PE-BK
Length L (Imperial)
100.0
Length L (Metric)
30.48
Variant
Spiral Binding
Bundle Diameter Min (Imperial)
0.31
Bundle Diameter Min (Metric)
7.92
Bundle Diameter Max (Imperial)
3.0
Bundle Diameter Max (Metric)
76.2
Diameter D (imperial)
0.375
Diameter D (metric)
9.53
Nominal Diameter (Imperial)
3/8
Nominal Diameter (Metric)
9.53
Wall Thickness WT (Imperial)
0.052
Wall Thickness WT (Metric)
1.32
Material
Polyethylene (PE)
Material Shortcut
PE
