Specification Sheet
Part Number:
181-00651
High Density Slotted Wall Wiring Duct, 3" X 1" Adhesive, PVC, Gray, 120ft/Carton
Article Number
181-00651
Type
SLHDA3X1
Color
Gray (GY)
Features & Benefits
• Narrow fingers reduce fanning of the wires to the terminal blocks, presenting
a neater appearance. • Each finger is provided with a double restriction to hold
wires in the bottom portion of the duct, allowing for easier installation. •
Mounting holes are uniform in size to the solid and slotted wall duct, but are
offered every 2 inches to accommodate compact designs and ease installation.
Quantity Per
carton
Product Description
Pro-Duct high density, slotted wall, wiring duct features narrow fingers,
equaling a 2 to 1 finger ratio compared to standard slotted wiring duct. With
the narrow fingers, compact designs and components are more easily
accommodated.
Short Description
High Density Slotted Wall Wiring Duct, 3" X 1" Adhesive, PVC, Gray,
120ft/Carton
Global Part Name
SLHDA3X1-PVC-GY
Technical Description
Adhesive
Length L (Imperial)
6.0
Length L (Metric)
1.83
Width W (Imperial)
3.0
Width W (Metric)
76.2
Height H (Imperial)
1.06
Height H (Metric)
26.9
Mounting Hole Centers (Imperial)
2.0
Material
Polyvinylchloride (PVC)
Material Shortcut
PVC
Flammability
Self-Extinguishing
Halogen free
No
Operating Temperature (Metric)
+122°F (+50°C)
