Specification Sheet
Part Number:
181-00473
Solid Wall Wiring Duct, 3" X 5", Non-Adhesive, PVC, Black, 120ft/Carton
Article Number
181-00473
Type
SD3X5
Color
Black (BK)
Features & Benefits
•
Solid wall construction provides excellent coverage to keep wires clean.
•
Durable material protects wires from damage, with long-lasting performance.
•
Available standard colors complement or contrast in light and dark
environments. •
Optional covers snap on and off easily, and are provided with a
non-slip lining that insures the covers remain in place during vibration.
Quantity Per
carton
Product Description
HellermannTyton’s Pro-Duct, Solid Wall wiring duct efficiently routes and
protects wire and cable. Solid Wall wiring duct it designed for straight wire
runs where break outs are not required. Pro-Duct, Solid Wall wiring duct is
manufactured from high impact, rigid PVC, comes in standard colors of white,
gray and black, and is available in 6 foot lengths.
Short Description
Solid Wall Wiring Duct, 3" X 5", Non-Adhesive, PVC, Black, 120ft/Carton
Global Part Name
SD3X5-PVC-BK
Technical Description
Non-Adhesive
Length L (Imperial)
6.0
Length L (Metric)
1.83
Width W (Imperial)
3.0
Width W (Metric)
76.2
Height H (Imperial)
5.06
Height H (Metric)
128.5
Mounting Hole Centers (Imperial)
4.0
Material
Polyvinylchloride (PVC)
Material Shortcut
PVC
Flammability
Self-Extinguishing
Halogen free
No
Operating Temperature (Metric)
+122°F (+50°C)
Reach Complaint(Article 33)
No
ROHS Complaint
Yes
Certification/Specification WEB
CSA EN 50085-2-3_1A UL EN 50085-1:2005 + A1:2013
UL Recognized (US)
Yes
Package Quantity(Imperial)
120
Package Quantity (Metric)
36.58
