Specification Sheet
Part Number:
181-00203
Solid Wall Wiring Duct, 4" x 2", Non-Adhesive, PVC, White, 30ft/Box
Article Number
181-00203
Type
SD4X2
Color
White (WH)
Features & Benefits
•
Solid wall construction provides excellent coverage to keep wires clean.
•
Durable material protects wires from damage, with long-lasting performance.
•
Available standard colors complement or contrast in light and dark
environments. •
Optional covers snap on and off easily, and are provided with a
non-slip lining that insures the covers remain in place during vibration.
Quantity Per
box
Product Description
HellermannTyton’s Pro-Duct, Solid Wall wiring duct efficiently routes and
protects wire and cable. Solid Wall wiring duct it designed for straight wire
runs where break outs are not required. Pro-Duct, Solid Wall wiring duct is
manufactured from high impact, rigid PVC, comes in standard colors of white,
gray and black, and is available in 6 foot lengths.
Short Description
Solid Wall Wiring Duct, 4" x 2", Non-Adhesive, PVC, White, 30ft/Box
Global Part Name
SD4X2-PVC-WH
Technical Description
Non-Adhesive
Length L (Imperial)
6.0
Length L (Metric)
1.83
Width W (Imperial)
4.0
Width W (Metric)
101.6
Height H (Imperial)
2.07
Height H (Metric)
52.6
Mounting Hole Centers (Imperial)
4.0
Material
Polyvinylchloride (PVC)
Material Shortcut
PVC
Flammability
Self-Extinguishing
Halogen free
No
Operating Temperature (Metric)
+122°F (+50°C)
