Specification Sheet
Part Number:
175REF
Rite-On Self-Laminating Label Refill, .75" x .75" x 3.0", VL, White, 90/roll
Article Number
590-01751
Type
175REF
Color
White (WH)
Features & Benefits
• Compact to easily fit in pants or shirt pockets. • Dispenser can be reloaded
over and over, making it cost effective to use. • Dispenser edge allows easy
removal of label liner. • Dispenser protects labels from dirt and moisture before
use, extending the life and quality of the labels.
Quantity Per
EA
Product Description
HellermannTyton’s Rite-On Markers are made from a flexible vinyl film and
used to mark wire and cable. The self-laminating labels have a clear tail which
seals the legend under clear vinyl, maintaining the quality of the labels. The
Rite-On markers are packaged in a reusable dispenser made from high impact
plastic which is resistant to oils and grease.
Short Description
Rite-On Self-Laminating Label Refill, .75" x .75" x 3.0", VL, White, 90/roll
Global Part Name
175REF-100-WH
Fixation Method
Pasting / Stick
Variant
Roller form
Width W (Imperial)
0.75
Width W (Metric)
19.05
Bundle Diameter Min (Imperial)
0.33
Bundle Diameter Min (Metric)
8.32
Outside Diameter Max(Imperial)
0.7
Outside Diameter Min (metric)
8.38
Outside Diameter Min(Imperial)
0.33
Outside Diameter Max (metric)
17.78
Material
Type 100, Vinyl (PVC), white (WH), self-laminating
Material Shortcut
100
Adhesive
Acrylic
