Specification Sheet
Part Number:
170-22500
Helagaine Braided Sleeving, 25 mm Dia, PA66, GY, 164ft/Reel
Article Number
170-22500
Type
HEGPA6625
Color
Gray (GY)
Features & Benefits
• Nylon monofilament construction weave offers a tight braid that provides full
coverage but will not rot or retain moisture. • Material performs well in wet
applications and where abiding substrate has a smooth surface.
Quantity Per
metre
Product Description
Helagaine Nylon Polyamide Expandable Braided Sleeving is a pliable yet
durable sleeve that protects against cuts, abrasion and excessive wear caused
by repetitive motion.
Short Description
Helagaine Braided Sleeving, 25 mm Dia, PA66, GY, 164ft/Reel
Global Part Name
HEGPA6625-PA66-GY
Length L (Imperial)
164.0
Length L (Metric)
50.0
Bundle Diameter Min (Imperial)
0.71
Bundle Diameter Min (Metric)
18
Bundle Diameter Max (Imperial)
1.1
Bundle Diameter Max (Metric)
28
Diameter D (imperial)
0.98
Diameter D (metric)
24.9
Nominal Diameter (Imperial)
1
Nominal Diameter (Metric)
25
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
FMVSS 302 UL 94 V2
Halogen free
Yes
Operating Temperature (Metric)
-76°F to +302°F (-60°C to +150°C)
