Specification Sheet
Part Number:
170-03160
Nomex® High Temperature Woven Sleeving, .38" Dia, GN, 100 ft/bulk reel
Article Number
170-03160
Type
BSNMX385B
Color
Green (GN)
Features & Benefits
•
Self extinguishing material does not melt and is unaffected by most acids, and
provides excellent thermal stability against direct flame. •
Provides excellent
thermal stability. •
Meets FMVSS 302 specifications for use in automotive
engineering. •
Material cuts with ordinary scissors which reduces assembly
time.
Quantity Per
reel
Product Description
A densely woven aramid fiber sleeving, this soft and flexible material is self
extinguishing and can withstand temperatures reaching up to 662°F. Excellent
for use in extremely harsh environments including those with exposure to
direct flame, high temperatures, as well as Beta, Gamma and X-Ray radiation -
in particular, military and aerospace wiring and harnessing applications.
Short Description
Nomex® High Temperature Woven Sleeving, .38" Dia, GN, 100 ft/bulk reel
Global Part Name
BSNMX385B-NOMEX®-GN
Length L (Imperial)
100.0
Length L (Metric)
30.48
Bundle Diameter Min (Imperial)
0.25
Bundle Diameter Min (Metric)
6.4
Bundle Diameter Max (Imperial)
0.5
Bundle Diameter Max (Metric)
12.7
Diameter D (imperial)
0.38
Diameter D (metric)
9.5
Nominal Diameter (Imperial)
3/8
Nominal Diameter (Metric)
9.7
Material
Polyaramid Polymetaphenylene Isophthalamide
Material Shortcut
NOMEX®
Flammability
UL VW-1
Halogen free
Yes
Operating Temperature (Metric)
-320°F to +662°F (-196 °C to +350 °C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
30.48
Customs Number
5806322000
Weight (Metric)
0.3
Weight (Imperial)
0.67
