Specification Sheet
Part Number:
170-03141
Braided Sleeving, Split Wrap, Flame Retardant, .25" Dia, PET, Black, 200 ft/bulk reel
Article Number
170-03141
Type
BSSWFR140B
Color
Black (BK)
Features & Benefits
•
Split wrap design installs quickly, saving assembly time and future
accessibility without disassembly. •
Unique construction retains shape and
rigidity throughout operating temperature range. •
Easy open design allows
quick assembly, future access, and ability to apply protective sleeving post
assembly or post installation situations. •
Self wrapping design eliminates the
need for fasteners. •
Provides a greater flexibility than spiralwrap or convoluted
tubing.
Quantity Per
box
Product Description
Used when flame retardancy is a primary requirement, this protection option
incorporates a lateral split which allows the tube to open up to accommodate a
variety of bundling requirements. The semi-rigid braid configuration simply
closes around the entire installation without the need for any additional
fasteners. Split wrap flame retardant braided sleeving is self-extinguishing and
complies with UL VW-1 standards where cables exit a wall and need to be
managed for an uncluttered, clean appearance.
Short Description
Braided Sleeving, Split Wrap, Flame Retardant, .25" Dia, PET, Black, 200
ft/bulk reel
Global Part Name
BSSWFR140B-PET-BK
Length L (Imperial)
200.0
Length L (Metric)
61.0
Bundle Diameter Min (Imperial)
0.1
Bundle Diameter Min (Metric)
2.54
Bundle Diameter Max (Imperial)
0.25
Bundle Diameter Max (Metric)
6.4
Diameter D (imperial)
0.25
Diameter D (metric)
3.2
Nominal Diameter (Imperial)
1/4
Nominal Diameter (Metric)
6.4
Wall Thickness WT (Imperial)
0.025
