Specification Sheet
Part Number:
170-03088
Braided Sleeving, Split Wrap, 2" Dia, PET, Orange, 50 ft/bulk reel
Article Number
170-03088
Type
BSPSW203B
Color
Orange (OG)
Features & Benefits
•
Split wrap design needs no fasteners and installs quickly, saving assembly
time and future accessibility without disassembly. •
Bends to a tight radius
without distortion or splitting open. •
Unique construction retains shape and
rigidity throughout unrolling. •
Easy open design allows quick access and ability
to apply protective sleeving post assembly or post installation situations.
Quantity Per
reel
Product Description
A lateral split, semi-rigid and flame retardant braided sleeving configuration
used when ease of installation and repeat access to wire bundle is required.
The lateral split allows the sleeving to open and accommodate a variety of
bundling requirements. The 25% edge overlap rolls back over connectors and
splices without exposing the bundled wires.
Short Description
Braided Sleeving, Split Wrap, 2" Dia, PET, Orange, 50 ft/bulk reel
Global Part Name
BSPSW203B-PET-OG
Length L (Imperial)
50.0
Length L (Metric)
15.2
Bundle Diameter Min (Imperial)
0.1
Bundle Diameter Min (Metric)
2.54
Bundle Diameter Max (Imperial)
2.0
Bundle Diameter Max (Metric)
50.8
Diameter D (imperial)
2.0
Diameter D (metric)
50.8
Nominal Diameter (Imperial)
2
Nominal Diameter (Metric)
50.8
Wall Thickness WT (Imperial)
0.038
Wall Thickness WT (Metric)
0.97
Material
Polyester (PET)
