Specification Sheet
Part Number:
170-03072
Braided Sleeving, Expandable, Flame Retardant, .25" Dia, PET, Gray, 200 ft/reel
Article Number
170-03072
Type
BSPFR148
Color
Gray (GY)
Features & Benefits
• Treated polyester material contains a combustion inhibitor for use in
applications where flame retardancy is required. • Braided design allows
sleeving to expand by 150% to accommodate variations in wire bundle and
eases installation.
Quantity Per
reel
Product Description
A flame retardant woven (threaded) polyester sleeving that is resistant to cuts
and abrasion, and contains a combustion inhibitor allowing it to achieve a UL
and CSA flame resistance rating of VW-1. Contains white tracer thread for
easy identification.
Short Description
Braided Sleeving, Expandable, Flame Retardant, .25" Dia, PET, Gray, 200
ft/reel
Global Part Name
BSPFR148-PET-GY
Length L (Imperial)
200.0
Length L (Metric)
61.0
Bundle Diameter Min (Imperial)
0.125
Bundle Diameter Min (Metric)
3.2
Bundle Diameter Max (Imperial)
0.437
Bundle Diameter Max (Metric)
11.1
Diameter D (imperial)
0.25
Diameter D (metric)
6.4
Nominal Diameter (Imperial)
1/4
Nominal Diameter (Metric)
6.4
Material
Polyester (PET)
Material Shortcut
PET
Flammability
Mil-202 FMVSS 302 FAR 25 UL VW-1
