Specification Sheet
Part Number:
170-03066
Braided Sleeving, Expandable, Flame Retardant, 1.5" Dia, PET, Gray, 40 ft/reel
Article Number
170-03066
Type
BSPFR1128
Color
Gray (GY)
Features & Benefits
• Treated polyester material contains a combustion inhibitor for use in
applications where flame retardancy is required. • Braided design allows
sleeving to expand by 150% to accommodate variations in wire bundle and
eases installation.
Quantity Per
reel
Product Description
A flame retardant woven (threaded) polyester sleeving that is resistant to cuts
and abrasion, and contains a combustion inhibitor allowing it to achieve a UL
and CSA flame resistance rating of VW-1. Contains white tracer thread for
easy identification.
Short Description
Braided Sleeving, Expandable, Flame Retardant, 1.5" Dia, PET, Gray, 40 ft/reel
Global Part Name
BSPFR1128-PET-GY
Length L (Imperial)
40.0
Length L (Metric)
12.2
Bundle Diameter Min (Imperial)
1.0
Bundle Diameter Min (Metric)
25.4
Bundle Diameter Max (Imperial)
2.125
Bundle Diameter Max (Metric)
53.9
Diameter D (imperial)
1.50
Diameter D (metric)
38.1
Nominal Diameter (Imperial)
1-1/2
Nominal Diameter (Metric)
38.1
Material
Polyester (PET)
Material Shortcut
PET
Flammability
UL VW-1 FMVSS 302 Mil-202 FAR 25
Halogen free
Yes
