Specification Sheet
Part Number:
170-03000
Braided Sleeving, Expandable, .25" Dia, PET, Black, 200 ft/reel
Article Number
170-03000
Type
BSP140
Color
Black (BK)
Features & Benefits
• Weave construction adjusts to twisting and flexing without creating wrinkles
or bends. • Durable construction offers excellent abrasion and cut-through
resistance as well as inertness to most chemicals and fungus. • Color options
available to provide easy visual and safety identification of critical wiring
components. • Expands to 150% of nominal diameter for fast, easy installation.
Quantity Per
reel
Product Description
Designed to adjust and expand to irregular shapes, this general purpose
sleeving is lightweight and offers a high tensile strength while still maintaining
flexibility. This sleeving is an excellent choice for protecting wire and cable
bundles from abrasion, chafing and heat degradation. Commonly used in
electrial and industrial wire harnessing application where economy and
durability are required for the protection of wires, cables, tubing, bundles and
pneumatic hoses.
Short Description
Braided Sleeving, Expandable, .25" Dia, PET, Black, 200 ft/reel
Global Part Name
BSP140-PET-BK
Length L (Imperial)
200.0
Length L (Metric)
61.0
Bundle Diameter Min (Imperial)
0.125
Bundle Diameter Min (Metric)
3.2
Bundle Diameter Max (Imperial)
0.437
Bundle Diameter Max (Metric)
11.1
Diameter D (imperial)
0.25
Diameter D (metric)
6.4
Nominal Diameter (Imperial)
1/4
Nominal Diameter (Metric)
6.4
Material
Polyester (PET)
Material Shortcut
PET
Flammability
FAR 25 FMVSS 302 UL 94 V0
Halogen free
Yes
Operating Temperature (Metric)
-94°F to +257°F (-70°C to +125°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
UL Recognized (US)
Yes
Package Quantity(Imperial)
200
Package Quantity (Metric)
60.96
Customs Number
5808100000
Weight (Metric)
0.24
Weight (Imperial)
0.52
