Specification Sheet
Part Number:
167-00205
Hinged Convoluted Loom Tubing Endclamp Fitting, 0.75", PP, Black, 2200/pkg
Article Number
167-00205
Type
CTHC-EC7
Color
Black (BK)
Features & Benefits
• Living hinge allows harness serviceability and reduces assembly time. •
Internal ribs affix to exterior of tubing which prevents slipping during tension or
movement. • Snap-on connection makes installations quick and easy and
increases efficiencies in harness assembly. • Junction point outlets offer
additional areas to branch off wires and prevents wires from sliding or
accidental removal from tubing. • Improves aesthics of assembled wire
harness. • No tools required to disassemble.
Quantity Per
carton
Product Description
Convoluted Loom fittings are single piece hinged connectors that simply
snap-on over slit and unslit loom tubing to secure wire branchouts or, connect
different tubing diameters. The unique wrap around design makes installation
easier and more efficient, while the unique junction points make easy
branchouts that keep wires from sliding out of the tubing and eliminates need
for secondary taping operation. The polypropylene material creates a sleek
assembly and improves the appearance of the entire wiring assembly.
Short Description
Hinged Convoluted Loom Tubing Endclamp Fitting, 0.75", PP, Black, 2200/pkg
Global Part Name
CTHC-EC7-PP-BK
Diameter D (imperial)
0.75
Diameter D (metric)
19.1
Material
Polypropylene (PP)
Material Shortcut
PP
Flammability
UL 94 HB
Halogen free
Yes
Operating Temperature (Metric)
-4°F to +194°F (-20°C to +90°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
2200
