Specification Sheet
Part Number:
166-90780
HelaGuard Non-Metallic Fitting, Conduit Coupler, IP66, 1.25 to 1.25" Dia, PA66, Black, 2/pkg
Article Number
166-90780
Type
HG125-HG125
Color
Black (BK)
Features & Benefits
•
One-piece fitting used to join conduits of same diameters. •
Snap-on
construction reduces installation time and costs by eliminating the need to
thread fittings onto conduits. •
All-around "teeth" attach firmly to conduit and
deliver a high extraction force. •
Durable nylon material has high resistance to
salts, oils, weak acids and solvents. •
IP66 ingress protection rating against
water, dust and wind.
Quantity Per
pack
Product Description
Used to join two same diameter corrugated conduits together, couplers feature
a snap-on design for a quick, secure connection. Designed for easy removal
with a small screwdriver. Suitable for use on all types of corrugated conduits,
both fine and course pitch material.
Short Description
HelaGuard Non-Metallic Fitting, Conduit Coupler, IP66, 1.25 to 1.25" Dia,
PA66, Black, 2/pkg
Global Part Name
HG125-HG125-PA66-BK
Length L (Imperial)
3.98
Variant
Coupler
Outside Diameter OD(Imperial)
2.48
Outside Diameter OD(metric)
63.0
Nominal Diameter (Imperial)
1-1/4
Nominal Diameter (Metric)
42
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Halogen free
Yes
Operating Temperature (Metric)
-58°F to +275°F (-50°C to +135°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
