Specification Sheet
Part Number:
166-90375
HelaGuard AFCP Smooth Tubing Clip,0.50" Dia, PA66, Black, 10/pkg
Article Number
166-90375
Type
AFCP0500
Color
Black (BK)
Features & Benefits
• Integrated flip open lid for quick and easy assembly. • Smooth inner surface
holds tubing from slipping. • Easy access mounting hole reduces installation
time. • Quick release for easy future access.
Quantity Per
pack
Product Description
Conduit Clips clamp onto corrugated conduits and tubing to secure. Nylon
material resists corrosion and chemicals. Can also be used on C-shaped DIN
rails.
Short Description
HelaGuard AFCP Smooth Tubing Clip,0.50" Dia, PA66, Black, 10/pkg
Global Part Name
AFCP0500-PA66-BK
Length L (Imperial)
1.26
Length L (Metric)
32
Variant
Clip
Width W (Imperial)
0.59
Width W (Metric)
15
Height H (Imperial)
1.42
Height H (Metric)
36
Nominal Diameter (Imperial)
1/2
Nominal Diameter (Metric)
20
Mounting Hole Diameter D (Imperial)
0.24
Mounting Hole Diameter D (Metric)
6.0 mm
Mounting Hole Diameter D Max (Metric)
6
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Operating Temperature (Metric)
-58°F to +275°F (-50°C to +135°C)
Package Quantity(Imperial)
10
Package Quantity (Metric)
10
Customs Number
3926909988
